N Style Magnetic Liquid Trap Magnetic Filters

Product Description

Magnetic filter, magnet filter in the liquid slurry transport process, the slurry through the filter, by the magnetic effect of the magnetic bar, the iron impurities of slurry are adsorbed on the magnet casing, greatly reducing the iron impurities of the liquid slurry, to ensure that the next process
can effectively control the iron impurity content. A magnetic filter is widely used in pigments, dyes, petrochemicals, pharmaceuticals, food, plastics, and other industries, in the liquid slurry transport process to effectively remove magical metal impurities, reduce the iron ions content of the product, improve product quality.
Magnetic filter with a small size, lightweight, easy installation, and operation advantages.

Features

1. We designed different styles for the use of different materials.

2. The maximum magnetic strength can reach 13000GS for normal (N Style) and 8000GS for easy cleaning (E Style).

3. Standard working temperature≤80℃, and maximum working temperature can reach 350℃ as required.

4. Easy installation, separation and cleaning through ferrule, bolt plate, flange or uneven head etc.

5. 304 or 316L stainless steel are available for pipeline material.

6. Ideal designed magnetic configuration ensures maximum magnetic effect without liquid flow impediment.

7. As required, specification of customer on pressure or other details is also available.

Standard Magnetic Liquid Trap Specification List:

Item No.	Flange/Connector	A	B	C	D	G	H	Bar Quantity
JL-159032	DN32	Ф159	230	80	Ф39	Ф110	Ф25	5
JL-159040	DN40	Ф159	230	80	Ф46	Ф110	Ф25	5
JL-159050	DN50	Ф159	230	80	Ф59	Ф110	Ф25	5
JL-219065	DN65	Ф219	300	100	Ф78	Ф150	Ф25	7
JL-219080	DN80	Ф219	300	100	Ф91	Ф150	Ф25	7
JL-219100	DN100	Ф219	300	100	Ф110	Ф150	Ф25	7
JL-273125	DN125	Ф273	330	100	Ф135	Ф200&Ф100	Ф25	10
JL-273150	DN150	Ф273	330	100	Ф161	Ф200&Ф100	Ф25	10
JL-325200	DN200	Ф325	360	114	Ф222	Ф250&Ф125	Ф25	13
JL-377250	DN250	Ф377	420	116	Ф276	Ф300&Ф160	Ф25	15
JL-426300	DN300	Ф426	460	118	Ф328	Ф340&Ф175	Ф25	17
JL-480350	DN350	Ф480	510	120	Ф381	Ф380&Ф200	Ф25	19
JL-630400	DN400	Ф630	700	135	Ф426		Ф25	21

Operation of Liquid Line Magnetic Ferrous Tube Trap Filter Separator

As liquids or slurries are pumped through the Liquid Trap separators, ferrous contaminants adhere to the magnetic tubes or magnetic bar. The design and construction allow the tramp iron to go around the downstream side of the tubes where it is safely out of product flow and wash-off is prevented. The cleaning job is achieved by removing the top plate and removing the magnetic assembly from the housing. The housing is designed not only to protect the magnet but also to act as a sump, to reach the easy-clean and fast-clean goal.
