Supported Single-dip All-steel Permanent Magnet Chuck

Supported Single-dip All-steel Permanent Magnet Chuck Use

Smaller workpieces can be used with this machine, and the accuracy is within 0.005mm.

Supported Single-dip All-steel Permanent Magnet Chuck Features

1. Permanent magnetic chuck with Nedymium magnets, strong magnetic force and less remaining magnetism
2. ON-OFF control by means of hand lever. In the OFF position,a weak opposing field eases the removal of the workpiece
3. Parralel fine pole pitch:6 mm(4mm of steel+2mm of brass)
4. Nominal holding force:100N/cm25. Pole plate wearing limit:5mm
6. Magnetic field height:6mm
7. coolant and water proof structure
8. parallelism, flatness and squareness 0.005mm/100mm

Supported Single-dip All-steel Permanent Magnet Chuck  Specifications
