Fine Pole Permanent Magnetic Chuck For Surface Grinder
Description of Fine Pole Permanent Magnetic Chuck For Surface Grinder
Fine pole permanent magnetic chuck for surface grinder is suitable to make the high precision planner sparker and linear cutting machining. Fine Pole Permanent Magnetic Chuck For Surface Grinder is 2um/100mm in the Plan precision and 0.5+1 in dic gauss. Since in a red structure, magnetic table for surface grinder will damage any workpieces and will make sure a good precision of the pieces. Magnetic table for surface grinder features and integrated wrench, long service life and special magnetic circuits with average magnetic force, the magnetic steel of 100N/cm2.
Specification of Fine Pole Permanent Magnetic Chuck For Surface Grinder
Model | Dimension(mm) | N.W | |||||||
A | B | B1 | C | F | G | G1 | H | ||
GMEPM 100X175 | 100 | 175 | 192 | 20 | 1.5(0.5+1) | 55 | 43 | 150 | 7 |
GMEPM 125X250 | 125 | 250 | 270 | 20 | 1.5(0.5+1) | 55 | 43 | 200 | 13 |
GMEPM 150X150 | 150 | 300 | 320 | 20 | 1.5(0.5+1) | 55 | 43 | 150 | 9.4 |
GMEPM 150X300 | 150 | 300 | 320 | 20 | 1.5(0.5+1) | 55 | 43 | 200 | 19 |
GMEPM 150X350 | 150 | 350 | 370 | 20 | 1.5(0.5+1) | 55 | 43 | 200 | 22 |
GMEPM 150X400 | 150 | 400 | 420 | 20 | 1.5(0.5+1) | 55 | 43 | 250 | 26 |
GMEPM 200X400 | 150 | 400 | 420 | 20 | 1.5(0.5+1) | 55 | 43 | 250 | 29 |
GMEPM 200X450 | 200 | 450 | 470 | 20 | 1.5(0.5+1) | 55 | 43 | 250 | 35 |
Note: This table shows the common specification. Optional for any special specification.
Instructions of Fine Pole Permanent Magnetic Chuck For Surface Grinder:
Packing of Magnetic Grinding Machine:
Process of Magnetic Grinding Machine:
